factory price LC single mode pigtails cable pigtail fiber optic pigtail
Product Description
The material of Ceramic Ferrule: Zirconium quality stable and easy for polishing
Fast delivery time(5-7days)
100% testing before shipment
All kinds of connector for option(SC,LC,FC,ST,MU,MTRJ,MPO/MTP,ODC,ODLC,SMA905 and so on)
Application
1)FTTH, LAN, PON & Optical CATV, Local ring net
2) Optical fiber communication system
3) Optical fiber test equipment
4) Optical fiber sensor
5) Industry and military application
Mode | Single mode | Multimode | |||
Polish | UPC | APC | PC | ||
Insertion Loss | ≤0.2dB | ≤0.2dB | ≤0.2dB | ||
Return Loss | ≥50dB | ≥60dB | ≥35dB | ||
Test Wavelength | 1310/1550nm | 850/1310nm | |||
Durability(500 Matings) | ≤0.2dB | ||||
Operating Temperature | -20℃~+70℃ | ||||
Storage Temperature | -40℃~+85℃ | ||||
Fire Resistant | IEC 60794-2-30 | ||||
Standards-Compliant | ROHS,IEC and GR-326 | ||||
Sample | YES | ||||
Delivery time | 1 days for sample, 3days for production | ||||
Fiber type | Single mode: |
Multimode: (8)50/125-OM5 | |
Fiber brand | YOFC, Corning, OFS... |
Connector type | SC, LC, FC, ST, E2000, MU, MTRJ, MPO/MTP, SMA, DIN |
Cord type | Simplex ,Duplex, 4cores, 6cores, 12cores, 24cores... |
Cable diameter | 0.9mm, 2.0mm, 3.0mm.... |
Cable jacket | PVC, LSZH, OFNR, OFNP |
Length(M) | 0.3m,1m,2m,5m,10m,25m,50m,100m |
Quick Details
Place of Origin:shanghai, China (Mainland)
Brand Name:Telsto
Model Number:LC UPC
Connector type:LC UPC
Diameter:0.9mm/2.0mm/3.0mm
Jacket material:LSZH/PVC
Length:1M,3M or customized length
Jacket color:yellow
fiber type:G652D/G657A1/G657A2
Insertion loss:<0.25dB
Return loss:>50dB
