Product Description
Where to buy coax connectors Din male to 7/8'' cable
Model: TEL-DINM.78-RFC
Description:
DIN 7/16 Male connector for 7/8’’ flexible RF cable
Technical Characteristics:
| Material and Plating | |
| Center contact | Brass / Silver Plating |
| Insulator | PTFE |
| Body & Outer Conductor | Brass / alloy plated with tri-alloy |
| Gasket | Silicon Rubber |
| Electrical Characteristics | |
| Characteristics Impedance | 50 Ohm |
| Frequency Range | DC~3 GHz |
| Insulation Resistance | ≥5000MΩ |
| Dielectric Strength | 4000 V rms |
| Center contact resistance | ≤0.4mΩ |
| Outer contact resistance | ≤1.0 mΩ |
| Insertion Loss | ≤0.05dB@3GHz |
| VSWR | ≤[email protected]GHz |
| Temperature range | -40~85℃ |
| PIM dBc(2×20W) | ≤-155 dBc(2×20W) |
| Waterproof | IP67 |
Quick Details
Place of Origin:shanghai, China (Mainland)
Brand Name:Telsto
Model Number:TEL-DINM.78-RFC
Type:Din 7/16
Gender:Male
ROHS Level:ROHS COMPLIANT
Business type:OEM & ODM
Lead time:7-10 days
Impedance:50 Ω
Temperature Range:-55~+155℃(PE Cable -40~+85)
